Does seem pretty nasty. Only thing that I don't like about the serato preset is I don't see a dedicated loop on/off or am I wrong?

Not sure yet. But it's 100% programmable and comes with a blank overlay...so you can just set it up the way you want to if something is not there.

I'm interested in this as well. I look forward to your review.

Already got one, it's pretty cool, better than my former Xone:1D that's for sure.

The overlay is just a .pdf, not a physical overlay. So if you want to print one out and go through all the joy of cutting lots of circles and rectangles out, it's great that way, I guess.

I picked one up recently after I tried it out. You can load the SSL preset that comes on the disc, but you'll probably still have to assign a few parameters from scratch, like loop length via the knobs. To do that, ignore NI's controller setup software after you install the SSL preset file, then just assign the controls in Scratch Live's MIDI assign mode. Once I got that done, it's been great fun to use, but I'm a bit annoyed by the sketchy setup process and the lack of a physical overlay in the box. I have yet to hear from NI as to why they didn't include one as their website says.

the setup is what makes me not want one, i LOVE my 1000 but im eyeballing this

Isn't funny how when I first posted about the X1 I got flammed by a lot of you. And now that it's out, all of the sudden lots of you want it. lol

Eitherway, I'm getting one. HEHEHE!!!

I posted about it as well months ago..I too was flamed :)

It's all good. I look forward to what works for me, and based on the shortcomings of the Denon unit, I never bought it. This one looks like it will fit much better into my workflow, plus it also looks like it will fit nicer alongside my mixer...like it was naturally supposed to be there.

Konix, I look forward to your thoughts! Here are a few questions:

1) When you program it do you still get the light feedback?
2) does it have another midi page (page 2)
3) do the lights work on page 2 (if it exists)
4) can you tell what midi page you are on easily (a light perhaps)

Hey Guys,

If you have any questions or difficulties, please join forum and post your questions or concerns here.

www.native-instruments.com

my favorite part of traktor and native instruments.... is the dj rafik videos.

Same here.

I find it interesting that you bought the unit without knowing the answers to those very major questions you posted. What shortcomings did you see in the Denon unit?

turntable,mixer,midi control,turntable, computer.

the order of my set up from left to right.I like how it sits between the mixer and turntable

Rebelguy, those are not deal breakers for me.

First off the position of the Denon unit doesn't work for me. Placing it above or below my mixer isn't natural, but placing it along side of my mixer fits better for me.

Also the Kontrol X1 has the ability to let me program both ScratchLive and VSL controls on the same page in a more "organic" set-up. The Denon unit does not lend itself to that flexibility.

The other issues are just bonus issues. If they turn out to be solvable then that just makes for a better unit.

1) Unfortunately no, not until Scratch Live supports MIDI output feedback
2) Yes, two pages
3) No, see 1
4) Yes, the Hotcue button is the only one that lights up (green), signifying the X1 is in MIDI mode, pressing the Shift button on the X1 switches to the second page, and will light up white.

Overall though, it's still a great controller, definitely prefer it over the Denon HC1000. I prefer the vertical orientation of the X1 versus the horizontal orientation of the HC1000. And with effects coming in SSL 2.0, you're going to need a lot of knobs, which the Denon lacks. The X1 is solid yet lightweight. If you've ever played with NI's Maschine, the X1 is on par build-quality wise with it. If only it the LEDs light up, it would be perfect as it looks very nice when lit-up. But alas, the LEDs only work if you use Traktor.

^^^ i want LEDs

Konix,

Thanks for taking your time to answer my questions. It seems like it will be a great addition to my set-up.

Hmm quick thought. Doesn't the Denon HC1000 light up in response to feedback from ScratchLive? Wouldn't that indicate that ScratchLive already supports MIDI output feedback?

^^^^ brings up a good point that makes me come to a conclusion....It's all about bandwidth.. SL1 and ttm57 are runing USB 1.0,they got video,and now efx on 1.0 bandwidth.thats damn good if you ask me.Now that the 68 and SL3 are 2.0 may be there will be enough bandwidth to make this happen?

midi output feedback that is!

i have had one for over a week now the... running it with 2.0 there is no controller that comes close blows the denon away.... LED do work in serato.. the set up takes about 5 mins and u have total control over all the effects.. loops in out... samples... pithch bend... everything and anything u want.. once again the LEDs do light up in serato... learn your product b4 u post!

konix is wrong about the LED's? i find it very strange! not calling BS but I think Konix has gained a bunch of respect around here.

Yea, I might need to side with Konix here as well.

ive used both and love the denon much more. just my opion.

Well, I could be wrong, granted I've only played around with my X1 for a couple hours. If you got the LEDs to work Richard Schmidt, I'd be curious to know how (yikes, Konix doesn't know something!). Are you using the included SSL_X1.XML map NI provides, or mapping it yourself?

Also I noticed on my PC, the LEDs do not light up at all, however, on my Mac, all the buttons are very dimly lit, but they do not get brighter when pressed or anything. Strange. I'll mess around some more with the Control Editor for the X1 and see what I find.

The Denon does light up on it's default pre-mapped page as Serato wrote special drivers for it, the buttons don't light in the other normal MIDI pages though. So Serato could theoretically possibly write special drivers for the X1 if the demand is great enough for it.

Well you have it Konix...that's demand enough!

no disrespect to konix however i do run it wit the LEDs on and very bright... i used the ssl.xml in the control editor mapped the effects knobs and everything my self just by hitting midi and turning the knob or hitting the button u want to midi map... just like u would map a nano control or aki mpd or mpk.. i have have them all

To get the LEDs to work u have to install traktor le which comes on the kontol x1 disc... go into the preferences and turn the LEDs up then closte traktor the LEDs will be on then switch back to serato and they remain on... this is for mac i can't resond to pc setup.

Can't wait until I get mine in next week.

you will love it best midi by far!!!!!!!!!

Well, I think we're talking about different things Richard. I've figured how to get all the lights to stay on and lit constantly (or all off), that's a preference in the Control Editor app (On-State brightness and Off-state brightness, which you can also set in Traktor as well), however, what we're talking about is getting the lights to act like in Traktor. That is, partially lit or not lit at all when not active, fully lit when active. And I'm happy to report I've got this working in Scratch Live, at least partially, took a bit of tweaking in the Control Editor app though. So, making progress.

^^^ i feel a vid coming soon!!

^That's alright, I'll wait for Paul the DJ to make one.

^^^^ Not that clown. Waiting for Konix's SL bible vid

Konix,

Is the control editor app shipped with the unit or are you talking about something else?

************
Sounds like a winner in the midi control stakes...awaits Video for perfect setup and then I'm on it!

Looks like March is gonna be expensive...A&H: DX + X1... I better get gigging some more!

K

Yes, there's an app on the install CD that you use to edit the X1...i48.photobucket.com

Thanks. I saw that picture before but couldn't find the program to download it.

I'll be asking more questions next week :)

LOL!!!!!!!!!!!!!!!

mmmm, delicious ;)

Watchwww.youtube.com

Not say the x1 isnt dope but after usieng both love the denon for mobile gigs and clubs much more. easier to use with scratch live and mapped the second scene to effets was easy to ,i love it.

There is not that many knobs on the denon unit, so I can still see it being limited.

sure the knob thing could be an issue but for a club dj or a mobile dj i lover it, there are enough knobs and pads for the effects i like to use and the denon is built so much better for being dragged around to gigs, its a tank. i love it like i said. works really well for what i need and had 3 empty scenes to map midi stuff so i love it

i LOVE the denon, its built like a tank and i love the natural feel with SL...that said i need more buttons and knobs for effects\video purposes.......i will be using both connected to a hub most likley like i am currently doing with the korg kontrol

Yeah I think that the difference between the x1 and the denon - more functions are available on the x1 especially for 2.0 without having to switch between scenes.

Well, I think the Denon is probably better suited if you're more interested in cue point/sample player triggering (bigger buttons), the X1 for effects (more knobs).

Makes sense, like i said ive used both and get the pros and cons of both. i have all denon stuff and love it,. its been a rock to me for 20 years so i stick with what works. Sure it would be nice to have more knobs and pads but when im doing clubs and gigs its just enough.

Any stores have deals on the X1's or do still retail for $200?

Hi guys,
got my X1 a few days ago and I love it.

Is there any possibility yet to use SSL's easter egg of Auto Loop with the controller? I'd love it if i just pressed shift while using the loop knob and it would auto loop instead of going back to the old position.

Any idea how to do that?

Tim

autoloop........easteregg....

loop roll

sorry, wrong term. does loop roll work with the x1?

yes...... konix has a vid on just that look it up

konix did it

not on the X1 but on another midi device that has a rotary knob

Tracking number received on my unit being shipped. Next week will be fun.

anybody got that link for for the X1 vid by konix... I have the denon but with the new 2.0 i think we need more knobs

i went tis youtube channel but he talks about midi mapping but not specific to the NI controller

I haven't made any videos yet for the X1, what do need help with though?

i had seen a video on youtube the other day and the guy had it mounted right above his 57 and it had like a 45 degree angle, any idea how he did this? Does it come with a stand or something.

The only "stand" you can purchase made specifically for it is the bag from NI. It's a protective bag and a 3-4 inch block so that it's even with a mixer.

If someone had it at a 45 degree angle, this was something they did themselves.

OK just received my Kontrol X1 and and juggling several things at once...but I plugged it in thinking that it would "automatically" work...and it doesn't.

I am positive this is operator error but anyone that has one know how to make the ScratchLive presets work?

M.Bezzle thanks for the info. I actually found the SSL midi file in their folder and only had a few minutes to play with it.

This definitely will take some practice before going live with it...I can see me screwing up by adding a new song with just the push of a button :)

First quick impressions: Knobs and buttons feel nice and solid. It's a bit wider than I thought it would be, good weight, solid feel. It will take some time using it and I will certainly have to re-program it before using it.

I did receive the physical overlay in the box but I can see that I will not be using the SSL side, just the blank side. Also getting the light feedback to work will be a learning process as well.

WIll it be worth the money, very first, very quick run-thru says yes.....I hope to have a better feel for that by this weekend.

whats the dubstep track in the video mate? very nice

To get the all of the LED lights working on the X1 with Serato open the X1 control editor and change all of the buttons from 'gate' to 'toggle.' The LEDs will not work as they should. If this causes problems in Serato as far as the buttons' 'on' (lit) position not corresponding to the on position of the serato button, change the button's type to relative - binary offset within Serato. Good to go, gloooowing buttons. I like to keep my 'off' buttons at a dim level too so they're never fully off and my X1 looks sexy.

video? Sorry I have denon controller but with new features in 2.0 trying to justify not switching to the X1, or to justify why I should. How does the autoloop work for you? and the loop roll? those functions are just so easy on the Denon... thanks

Holy Schmidt Konix get on that video LOL

This should have read: The LEDs will NOW work correctly.

I'll have videos up with the X1 and 2.0 in the next day or so.

And probably about 5+ more 2.0 videos :)

Overall before you do the video demo.

Yea or Ney on the X1?

Yep, but this is only good for on/off type buttons. Which for things like turning on/off the FX is great, but most other functions (cue points, loops, etc.) work better as a trigger or gate.



Overall Yea, depends on what you want from it though. FX? Most definitely.

you push down on the top of the rotary knob to activate the loop, then turn clock wise to increase the size of the loop & counter to decrease the size..

Perfect I'll get one from my shop in the morning LOL. thanks again.

--anxiously awaits video-- :}

i got a problem mapping this. the left auto cue scroll works and when i press the knob it turns it off/on perfectly just as it should. the RIGHT knob though scrolls no problem, but doesnt always turn it off/on when it should. sometimes it does and most of the time it doesnt

actually to clarify, the right knob always turns auto cue on when pressed, but does not always turn it off.

another question while im at it...how do you make the buttons glow at 1/2 the brightness when in the off position?

Go to the controller editor preferences, then under the controller tab you can adjust the off and on brightnesses.

hmm thats what i was hoping for, but when i set the off to 50, still no lights

any thoughts on the right auto cue knob only turning it on and not off?

Z0nkers,

I just wrote a quick programming guide for the X1. See if any of this solves your issues

www.scratchlive.net

Have you checked your midi note settings for the knob button in the control editor? It may have accidentally been changed.

checked midi note settings & are the same left/right. will check the guide, thanks everyone 4 the help...im sure others who pick up the x1 will be reading this thread :)

hmm well so far so good. it can be a lil tempermental it seems at times. still had the same prob with deselecting the auto loop on the right side, even though i mapped it to a button. but then all of a sudden it started to work fine.

sim im a lil nervous to try it live and have this autoloop get stuck, lol

other than that though, with some tweaking here and there within ssl midi setting and also the x1 editor, i found the right combination of ish to get it all working just spiffy. still not done, need to takle the effects section next, but got all the standard stuff i use mapped nicely. havent been able to get the lights to light up when in trigger mode though, would be kinda nice just as a visual confirmation when im slapping around the cue points quickly.

one day if i find the energy ill post my mapping here.

anyone know what to do with the green hotcue button?

ps/ the shift key is soooooo nice! althogh i havent tried yet, i can see how its gonna make the efx section swunderful

used my denon with effects last night, loved it.

dj-freestyle...
care to share how you mapped the denon to work with the effects. i know how to assign, i am asking what feature you assigned to what button/knob. thanks for the insight.

Sub Scape - Nothing's Wrong

Can someone hurry up and make a vid of the X1 with serato 2.0 please!

Trying to solve a few problems with it, the lights, and some feedback. Konix should have one out soon :)

i used scene two and i used the pads for on and off and the knobs for scrolling throught the different effects. it works really nice.

ok. i have the pads set up for on and off. i tried to set the knobs up to control the amount of effect on the superknob but it seems i can only map that to one effect. i wonder if i can control the amount with one of the buttons instead. trying to understand the whole midi mapping things...thanks!

When you assign the knob to the effects you have to change the setting so you can scroll through them, when you set it and the box turns green change the setting and one of them lets you scroll through effects then, i forget with one i dont have it in front of me.

Guys make sure you read my thread on programming the X1...it will give you some valuable hints, especially how ScratchLive AND the X1 Controller program work together. And review Konix's video on changing the midi programming in ScratchLive once you select it.

Looks like Dubfire from Deep Dish completely ditched the CDJ's & Vinyl for two X1's.

nightmoves.me

Hahaha :) Awesome response :)

Still no fix for this? I bought the X1 and Midi mapped it, all I can say is that it's effin' awesome for the new SSL2.0 effects and SP6 sampler.

Can team Serato please add the fix for the X1 led's to light up?

the lights work for me. you gotta go into the controller editor and then file > preferences > controller then adjust the light brightness there. also it depends on how you set it up within the editor map to toggle etc...and again it depends on your config within ssl itself

its def not easy to get going, but once you get it, it will be easy. the only thing i cant get it to do it light up when i press a button that isnt a toggle. like its not ON in the down mode then OFF in the up mode if acting as a trigger

You can get the LEDs to light when assigned as gate or trigger, but since SSL doesn't have MIDI output in order to light the LEDs, you'll need to use a third party MIDI translating program like Bome's MIDI translator, Pure Data, or MIDIpipe (which is what I'm using, Mac only). This will output MIDI back to the X1 and hence light the LEDs in all modes (toggle/trigger/gate). That's what I'm working on right now before I get my videos up.

Yea, and I keep hoping that Traktor will just change their controller software :)

can't wait. after i see this vid i will make me decision on what midi controller im going to use

We shouldn't HAVE to use 3 party apps for it to work. SSL should have a decent LPSI factor.

www.scratchlive.net

We will see, if enough of us bitch about it it could be a quick resolve. Since Abelton integration is soon, we need lights for our pretty controllers LOL

i have the effects switch assigned to buttons and lit up with toggle / binary offset
i have cue points assigned to button that won't light up with gate / absolute

all of the buttons are lit at about 25% so i can see them through the editors control preferences.

dunno how you are doing it, but i seem to be having the opposite problem you are, lol

The problem isn't really Serato's issue this time...yes it would be nice if Serato would do some more work on some midi feedback but with the X1 there are at least 4 different mode options (Toggle, Trigger, Gate, and Inc) AND there are 12 different type options...all of which add up to lots and lots of selection options.

In the case of the X1, it really is Traktor's to change. Let's hope they do make some changes in the near future.

MOFO! I changed the control change in the NI editor software to 'toggle' for the buttons and now it works. FML!

Thanks for the tip.

Spoke too soon. It sorta works. Yes it lights up but it takes too many clicks to engage and disengage the 'light' from the function.

In the Editor, change the "on" value to 64 and "off" value to 66 (default is 0 on 127 off), then it will work right and won't have to push the button 4 times.

OK Konix, how the hell did you find that out?

Carefully :)

I was trying all sorts of numbers but never came up with that combination. Excellent job!

i havent changed those numbers for anythign yet, but i know what yu are talking about. thats why ive been changing the setting within ssl. i just played with those until it worked like i needed. it depends on what you are using the buttons for. it you want it lit as ON and unlit when OFF, then i found toggle/ binary offset worked for me. if you use toggle / other combination, then it can make you double click.

what i havent been able to do yet, is make a trigger button light up for the instant and only when its pressed down...then back to normal what you take your finger off and it comes back to the up position. for cue points....

i got a gig in about 6 hours...gonna give it a go

Try using Gate instead of Trigger....and Konix's numbers as well. Mine's not in front of me right now or I would test that.

Just got one of these bad boys today, what a sweet controller. Haven't used it with SSL yet but it did come with an overlay. It works great with * Ummm, Traktor * Best purchase of the year. I'll fire it up with 2.0 in a bit. I am just not in the mood to do any mapping, I just like the things to work when I plug em in.

2.0 is not saving midi mappings at this time with any reliability. Just an FYI

the pioneers of the midi controllers!!! thanx allen and konix and the others for doing this work first before anyone

Actually it works set up like this better.

NI Editor Software: TOGGLE Value OFF: 0 ON: 127

Serato SSL2.0 Midi: Relative - Binary

The only glitch is (either Konix or the above way) is for example when you assign the DJ FX (button FX1 on X1) to expand the DJ FX and the SP6 (button FX2 on X1) to expand the sampler and your select either button first, then select the second they both stay lit. Although one collapses and the other opens. The only work around is to press the button to collapse that function before opening the next. Kinda lame.


I've noticed that too.

that sux!

Yeah, I'm checking in XLM and it seems that the midi is saving but when loading the midi preset back into SSL2.0 it doesn't take.

Is it USB-powered?

^^^ yes it ts

ts=is

Awesome! Thanks.

*unsubscribes*

Alright kiddies, here you go

Traktor Kontrol X1 with Scratch Live 2.0

part 1 - Watchwww.youtube.com
part 2 - Watchwww.youtube.com

For best results, watch on Youtube and not embedded here, in HD (720p) and full screened.

damn Konix uppin the anty on the vids, how much longer before we have a CGI konix doin demos

once again, thanx konix

I received mine 2 days ago!!! Highly recommend!!!!!

I borrowed my friends X1 for a gig. Now I have one coming in on Monday.

@Konix.

Thanx for the tutorials, man.

Much gratitude.

humm intresting!!
www.thebreakdown.co.uk

I believe we'll definitely see at least an X2, if not an X4.

What i'd really like to know is will one of them be a soundcard as well?

Irrelevant of course, since it won't work with Serato, but the addition of audio would effect the price point.

has anyone checked out the Vestax VCM 600..
looks rad!!

Watchwww.youtube.com

Watchwww.youtube.com

Watchwww.youtube.com

Watchwww.youtube.com

************
Lots of EDM DJ's work Traktor with AutoSync on and have started switching to midi only options!

Not a great look in my opinion but is certainly catching on within the scene by some big players.

K

So last night was my first night using the X1 in a club setting and not using my Trigger Finger.

Wow. What a great piece of equipment this X1 is. I used it all night long and had zero issues with it, everything worked great and I found myself using video effects much more since they were easier to get to. (I re-programmed the X1).

I 100% recommend this piece of equipment as a must have.

Now they need to come out with one that has sliders...and fix the multiple controllers on the same system issue.

I tend to believe Serato DOES have MIDI output, because (AFAIK, I don't own one) the lights of the Denon DN-HC1000S ARE controlled by Serato. The Denon's LEDs are controlled by MIDI messages:
www.denondj.com

So I highly suspect the MIDI out feature is locked, but does exist!

Serato=SSL, of course

not on the scenes you map, the only time the feedback lights work is on the preprogrammed scene 1 so it sounds like a workaround for me

Nice video! Has anyone tried it with Internal mode?

how can i assign 2 buttons for the same thing? like the browse /scrooling assign on this video ? both buttons scroll the library.
thanks in advance
jepe

got it... thanks anyway

And the answer to that is in the Controller Editor software set the Number field to the same number for both (or multiple) controls.

And the answer to that is in the Controller Editor software set the Number field to the same number for both (or multiple) controls.

true:) thanks!

man these things must be going like hot cakes. lots of places sold out. i already bought the hard case/stand in anticipation!

Where did you get the case/stand at?

a local shop but most places have them. bhphotovideo.com or turntablelab.com both have them i believe

whoops turntablelab is out but b&h still has them it looks like:

www.bhphotovideo.com

I just ordered mine the other day. Samash is the only local store in South florida that sells them and they have zero within the company right now. So I just have to wait till they get them. They said N.I. is shipping most out mid March... :-( . This is replacing my LPD8 and I can't wait to get this....

Yeah, from what I hear, the X1 is sold out at most places in the USA.

Ya... I really want to try this thing out.

Konix, First I want to say "thanks for all your videos!!!!" It's always been a big help. I saw how you have your X1 set up. Is their a way to put your midi info into a file that I can install and get mine up and running just like yours with out me having to map it out?

Yes, I can upload my mappings.

You should... I'm sure alot of people would use it. will it work for a windows pc? Would I still need to get that midi program to configure the leds to light up?

I know this comes with a template that goes over the controler for Serato. I saw the button configuration for it. It looks pretty god for 1.9.2. And I know this has a second page that can be mapped to whatever you want. I was wondering if their is a way to leave pg (1) as the way they configued it to work with their template for 1.9.2 and use pg (2) to work the fx's for 2.0 and other things someone would want to map/add to pg (2) with all the led's to light up?

I have a 57 which I mount on the turntable cases using its ears. A lot of the videos seem to have this placed between the mixer and the turntable. Is there a stand or something else to mount this on so it is easily accessible? I don't want to have to move to the end of the table to mess with it, I like everything right in front of me.

So I just got off the phone with Native Instruments. They said they won't receive their shipment of the Kontrol X1 till March 18th. Then they shill have to ship them out to all their vendors after that. So I'm sure it won't be on any shelves till at least the end of the month... that really sucks!!! :-(

I just had a vendor sell part of my order that he had in stock to another buyer. Needless to say I will not be buying from that vendor again.

Thats why i love my denon midi, it sits right in front of my mixer and does exactly what i need , effects and all.

my mixer has the damn headphone jack in the front blocking me from a perfect place to put it..DOHH

get an L-shape 1/4" adapter.

probably wont completely solve the problem but might help!

i have the denon mixer so it sits in front nicely but if you go onto the denon forum website some dude has built some really nice legs for it, i think his name is dboy, there pretty dope.

Does anyone know who has the Kontrol X1 in stock??? I pre ordered mine with Samash but I wont get it for another month and don't feel like waiting that long... it's B/S... I can just get my money back and order it online. Can someone let me know who has them please???

Thanks,

Jason

Try DJsupply.com, they may still have some.

Damm that was fast... thanks bro!!!!

i Portugal...
bought mine last week

www.mk2.pt

No luck there... :-(

He had some last week...they are going fast :)

Ya... he said Bad Boy Bill came in and other big DJ's bought the rest. I can't find it anywhere... I want this soooo bad!!! I hate waiting a few days foe things but this is a few weeks. lol...

n.i. is going to make a ton of money selling these things

No kidding.... Everyone is looking for them. They must be loving it... I'm shocked Rane doesn't have a Sratchlive version to this. If it was at the same price point it would do really well.

yea i bet rane is like "fuuuucccckkk why didn't we do something like this"

www.axemusic.com we always have 4 instock in our store and online warehouse.

FYI Rane Sixty-Eight will be available end of April for around $2976.00 + GST CDN, I just confirmation today.

Damn it... they have them but can't ship the United States.

Sorry guys, Canadian orders only LOL. To whom ever called from SFLA. I'm sorry I didnt mean to get you all hyped.

Oh I see how it is... ;-p

try midwest stereo on chicago, its www.midweststereo.com, when everybody was out of the denon midi they had iot

There my hidden jem.

What... they want $250 for it when everyone selles them for $200. But I did call Hollywooddj.com today and the guy said that N.I. was gonna raise the price to $250 and I thought he was full of sh**. Maybe he was right??? It's just what he said... I have no idea...

Me either , did midwest have it?

They r usally a little more exspensive but they always have what i need when everybody else doesnt.

call i bet they will come down on price.

i will call and see.

Nope.... nothing.... They are out too. I guess I have to wail like everyone else... Thanks guys for trying though... :-)

cool, hope it helps. i am there all the time and i saw one in the case last week so i bet they have them

wow, im shocked, hot item. crazy.

Try Bernie at Audiolines.com or Ben at NLFXpro.com

I think I tryed Audiolines this morning and they were out. I never seen nlfxpro.com but i will give them a shoot.

lmao... no & no...

Adam at www.CSNL.com

^^^ post fail lol...

I was going to say : because both ssl and tracktor guys use it.

Nope...

I am out of ideas :)

haha.. me too...

Guitar center has one in "mint condition" online in stock now. $175 -sweet. Oh btw, I love this thing. It's one of the best purchases I've made all year. Instead of packing a coffin with cdj's into a small booth at the club I just bring the mixer and this controller and go for it. Last Friday night was a blast with this controller. Yeah, I'm occassionally leaving the CDJ 2k's at home for my lil $200 controller, amazing. Get em while they're hot!

www.guitarcenter.com

I thought about a used one but figured it was way too soon for any to be returned.

Ya... me too... I would rather wait for a new one....

Seriously, just that and a mixer, need i say more.

Are you guys remapping it to work without your cd/turntables? I use CDJ1000MK3's and I'm trying to not have to take them out of my house. I don't see how to control the songs with just using the Kontrol X!. Are you using two of them?

How would u blend and scratch?

When I say controling the song I mean fast forward & rewind. And bend the tracks.

I scratch a lot so I hate when I dont have them around.

ya im really lost, i need to feel the record or platter to spin. period

I have been reading that people have been just using the Kontrol X1 withot cdj/turntables. But I'm sure thats fine when Traktor has the sync fet. Then dj's can just cheat all day long I guess.

You cannot use 2 of the X1's at the same time yet. They have said they will fix that with future releases.

most macs only have two usb ports anyway

after an sl1/sl3 is plugged you're only gonna be able to use one

Use a 2.0 USB Hub. That's what I do with my 2 midi devices I currently use.

Are you using a powered USB hub? I use a PC and I'm kinda worried about getting USB dropouts if I plug in a hub or getting them using the Kontrol X1. I never got them when I added the LPD8 from AKAI so I hope I will be fine...

I do use a powered hub. It's this one:

www.amazon.com

and I use a usb extension cable to keep it off to the side.

i dont use a powered hub, i bought a $5 usb 2.0 hub from office max and have the dennon hc1000 and korg kontrol pad hooked up to is, SL1 on the other USB port...0 issues

Let me guess... you got a Mac?? :-)

bezzle can u use the x1 and denon together with serato?

You can. The X1 allows you to change the midi channel so they do not conflict.

yup.... :)

when i finally find a spot to buy one thats not outta stock ill let ya know lol

Good luck with that...lol.

cool, we one have at the club but i have my denon at home, ill grab a x1 when they r back. i love my denon but haveing both would really put it on lock. They r haveing a workshop at the club in the city friday with the x1 and traxtor, no serato love but its all good.

Found an x1 last night, very nice. just broke it out of the box. :)

Who has them?

Yeah, I guess I was cheating when just using the controller with a mixer. I was using the Traktor Kontrol X1 with Traktor. Please forgive. I understand where you are coming from though, I prefer using CDJ's but in a pinch it's a nice setup. I'm still not sure 100% if utilizing the SYNC is cheating as compared to lining up the red and white sticks in Serato. I won't get into that here though. I would love to use SSL in a lighter setup if it allowed me to just use a controller. Not all my gigs allow space for my full coffin.

I'm in the same boat as you. I would like to stop bringing my cdj's to some events.

Where? I found a website last night that said they had them in stock. It's a small store in the midwest somewhere. I emailed them and they replied back saying they did have it. I called right now to verify and the lady said she had just sent me an email saying it's she's sold out. :( Sure enough, I did get the email. :(

I was just screwing around the other day and using my DJM-800 and my X1 and that was it. I mapped channel 3 & 4 volume sliders to left and right pitch control.

It was pretty wild but I am not sure I have the cojones to just bring those two items only to a gig.

i have a friend at gc who was out of town and came back yesterday and his ni rep had one for me. i got lucky. good timeing, i like it, still way more comfortable on denon midi but im getting used to it today. love them both for sure.

i tried usieng no cdjs or tables and boy that blows. how boring, takes all the fun out of it for sure. even after 20 years i still love it.

HURRY OUT to Guitar Center. They just got them today. I just got mine and it did come with a physical Serato overlay.

livemag.site.aplus.net

yo. .. that's. Worse then puging p$%#y in my face.

Sorry... my damn phone...

I just want my x1....

+1

I got mine yesterday. Last one GC had left.

***************
Can someone whack up a clear shot of the SSL overlay on the X1... Woody?

Be nice to see the options on the first scene.

K

i48.photobucket.com

Some picture of the overlay that I took with my phone.

i327.photobucket.com

i327.photobucket.com

i327.photobucket.com

i327.photobucket.com

i327.photobucket.com

When you turn it over it blank which is nice because it hides the words written on the unit.

yaaaaaa!!!! I got the last one today... Thanks Djwoody!!!! I don't know how G.C. got some??

I guess i'm an idiot... I can't get serato to recognize the x1? hotcue is lit up...thats it. I was just gonna start using it with the version it has just for now. Is their something I need to put into seratos midi file?

check the videos :
Watchwww.youtube.com
also part 2

oh I did... I was just gonna use the default one. I read somewhere that I had to copy a file and make a midi file in the scratchlive folder. I did that and I get nothing.

So this unit is not plug n play with serato?

did you did the install? from the cd? intall the drivers/controller editor?

yup... Should Serato recognize the x1 from just installing the drivers/controller editor? I am able to make my template work if i start from scratch and map it myself. It works that way buy I ran into a problem when trying to assign the browse knobs, cuz you can't assign two. Do you think I messed up the install some how?

First you have to select the Serato Scratch Live template in the X1's Controller Editor software. Then included on the install CD is the xml file for Scratch Live for the X1, you need to copy this file into your ~/Music/ScratchLIVE/MIDI folder. Then you have to load it in Scratch Live's setup menu on the MIDI tab page.

Also in order to get both knobs to scroll through crates/tracks, you have to assign them the same CC# in the Control Editor.

Now that ive used both for awhile, i really like the denon better. go figure.

Thanks Bro.. I'm watching your vids right now. I think I'm just gonna map my own. seems to be working well that way. I did assign them the same number cc16 or cc17 but I can only use one knob at a time. Konix... I wish you were right around the corner...lol

Ok I got it... Thanks guys!!!!

This thing rocks. I did have a question on the midi mapping software though. Is their any software that DOES NOT have to run in the background when using the controller? Like something I can just set up one time. I'm sorry for asking all these questions about this. It's just MIDI stuff is new to me and I'm just learning all of this for the first time. I tried to find Bomes light but all I could find was the demo Bomes. Also... I have no idea what to do once I open that software. I did do the same thing that Konix did (Midi in / Midi out) and was able to see the Tractor controller but I couldn't do anything with it. I'm using a PC. Is their a better program to use?

Also... When using page (2) on the controller, I saw Konix just press the shift button down without holding it and it stays on page (2). When I press it I have to hold it down to stay on page (2). Do I have to set that button in the controller editor as a toggle or something for it to work that way. And what does HOTCUE do? It just stays lit green on my x1. Thanks guys for your help!!!

You have to assign the shift button as a toggle instead of hold in the Controller Editor.

If you want the LEDs to light, yes you have to use an external MIDI program, until Serato implements MIDI output in Scratch Live. With Bome's I think you have to map each button individually to light up, which is a pain.

Yes Bome's has to stay open in the background. On PCs, there are two versions of Bome's, the Pro version, and the Classic version. The Classic version (www.bome.com) is free, and has limited functionality compared to Pro. The Pro version costs money and does more stuff.

Hotcue button does nothing in normal MIDI mode, it's only for when using Traktor Pro in native mode, it switches to the cue point setting/triggering page.

Thank's Konix... I really love this controller bro... Thanks for all your videos and support. When I get home from work I am gonna download The classic Bomes software and work on that tonight. Now I just need to design a bracket to mount it to the side of my coffin out of some kind of thin metal that I bent into the right shape so I can slide it down the side of the coffin and it will support the x1 right on the side.

Some thing like this...
_
I I
I I_______________I
I
The metal will rap around the side of the coffin and tuck down the side of the foam and run up the top the back down at the right height so that the X1 is flush with the top of my coffin.

Well I think I found a good stand for the X1. I was gonna try to design a bracket to mount on the side of my coffin. But I found this:

www.samash.com

All I need to do is trim the sides a little bit with a jig saw then file down the edges. I can then place it right behind my coffin so that it's right next to my laptop and it will be at the perfect angle. I'm gonna pick it up today.

***********
Good looking out on the photo's, I'll go ahead an pick one up now!

... then we just need some nice Midi Maps to be stickied for us :)

K

This one will work better because the top plate mounting bracket is not as wide so it can be cut down some more.

www.samash.com

The top can be at any angle you want too... its fully adjustable to any height/angle.

i was just going to get the X1 bag/stand

www.turntablelab.com

My bag / stand comes in today. I'm only using it as the bag though. I can only use it as a stand when I'm at the club. I also do alot of mobile stuff and have a coffin so I need something to support it.

How is the quality of the bag. Does it brings the controller to an even level with the mixer and TTs?

From what I have seen... yes . I will know for sure today though.

Yes, it's designed to. The quality's fine. Nothing really amazing, but it's well designed. The velcro tabs that unfold to support the X1 are a bit fussy; they keep catching on the bottom and sides of the bag, so it usually takes me a few tries to position them.

I just got mine... It really not worth $40 but what else can you use. I did need it so I would recommend it .

i got the rain stand for my denon and love it, right above my mixer. useing it and the x1 is really dope.

XI looks nice, but so much of still looks/feels like a band-aid that only get's you about 75% where you need to be (like the DNHC1000S). Have said before (many times) and will say it again: RANE needs to be the one designing and manufacturing true, professional, industrial-grade, SL-native, SL born n' bred controllers for use with SL. No one knows the product better and how it's used in the field, and IMO, no one makes better hardware for this type of stuff than RANE.

yeah +1000

they also need to come out with a wicked digital-spinning platter-HID-controller for ssl. it's time.

Can I just say "I HATE MIDI"............ So just when I think I have everything mapped out... I go to test it out and something is not assigned. The midi box in serato is gray not green. So I reassign it... that one works but now something else is not assigned. And the numbers on the controller editor keep changing on their own. I don't get it??? I save everything in serato and in the controller editor software. I got everything to work by the end of the night but I'm sure when I test it tonight things will be missing. :-(

Also, I have no clue how to use Bome's software to use the LED's. I click on Midi in or Midi out... I can see Trakto X1 but It can't do anything with it. I just says somthing about an error. Can someone chime in and give me a tip on how to use it. I would mess with it but I don't want to screw anything up.

I'm starting to lose my patience with this...

Thanks guys!!!!

Thats why i love the denon, not one issue. Works like a charm.

lol The X1 also works like a charm. The biggest difference is that the X1 is 100% programmable, has more options to it, and fits the workspace (at least mine) better than the Denon.

jroc453

Read this thread and see if it helps you at all

www.scratchlive.net

I have 3 empty scenes in the denon that are fully programmable and the denon sits perfect at top of my mixer so its a perfect extension of my mixer, im useing both and love the denon much more by far.

Thanks Justin... for both of my post's... I guess your search box works better then mine...lol ;-p

but its just my opion, i see both sides for sure.

for me personally thats its biggest drawback, i hate having to program things by myself i can never decide the optimal place to put things and i hate knowing that i have to leave some things out in exchange for others, i also end up changing what buttons back and forth so its hard for me to remmebr whats what, i like to buy a unit thats preprogrammed and labeled

Justin, I see how you set yours up. I do have a question though... you wrote :
TYPE: Control Change
MODE: Toggle
ACTION ON: Down

That will make the the LED light up, but wont it stay lit cuz it's a toggle? Can you use that configuration for cues? I thought it needed to be set as a gate??

That's where the Brome software comes in. I choose (in the beginning) to not worry too much about the lights and concentrate on the functionally. Then Konix came along and solved the light issue.

I have all of my lights set-up at 50% dimming and just look at my screen mostly...it's getting so I really don't have to look too much at the controller.

So there is a difference between mine and Konix's set-up.

I am hoping that Serato will look into more midi functionally within the next several months so we do not need a program like brome's.

Even though I have received my Kontrol X1 I just wanted to post this email I just got for everyone who is waiting for them....

Hi
We would like to thank all of you who preordered this item for your patience in waiting.
Our Native Instruments Rep had a conference call with head office last night and was told they should at last arrive at Native on Wednesday of this week and will start shipping on Friday 26th to dealers. We have not yet had any confirmation on the number of units we will be receiving. If we receive all that we have ordered, we will have more than enough to cover all backorders.
We therefore should be shipping these units out towards the end of the week of 29th.
As soon as we get tracking information of the shipment coming to us, we will forward the ship date to all customers.
Again, thanks for your patience.
Best regards
Julie

I'm sure this will be the case for most vendors... just FYI!!!!

Anyone know how to use Bomes??? I still don't know how to set up the lights on the Kontrol X1 using Bomes..

i got a question.
can you use 2 - X1'S to control ssl? (pretty sure you can)
and what is the with & lenght of these units?

im desiding on 2 - X1's or 1 of the Denon's.
im selling my Stanton 3D's. fuckers never fix issues with the firmwear.

no more stanton products for me.

DJ BuddyLove

At this time using 2 X1 creates issues. The X1's cannot tell each other apart :) Native has said that they plan on addressing this issue with a new update.

cool thanks for the info.
guess ill hold off until they adress the issue.

The place where I'm getting a second X1 said pretty much the same thing, in case anyone needed a second opinion.

thanx jroc453

been using it for the past week. pretty cool...especially with the lights off and tha back lights on the X1 lit up. i was a bit reluctant at first as anything with NI association usually gets my shitcan right from the start. however, i agree with the above....def one of the top midi controllers out there right now. only thing it's lacking IMO is a fader control (to use with VSL), otherwise it's top notch.

I wouldn't be surprised if in a month or so if Traktor doesn't come out with a companion piece that has exactly that feniks.

I think it's also missing a 5th push button in addition to the crossfader. This would be an ideal configuration, in addition to the crossfader off course.

Push Button Top Left - VSL Effects for Left Deck
Push Button Top Right - VSL Effects for Right Deck
Push Button Top MIDDLE (MISSING BUTTON) - VSL Effects for the Main Output

Push Button Bottom Left - Loops Left Deck
Push Button Right - Loops Right Deck

photos-d.ak.fbcdn.net

Here is my VSL set-up

Starting on the left side
Button 1 Opens VSL
Knob 1 gain control left side

Button 2 opens left effect 1
Knob 2 scrolls left effect 1

Button 3 opens left effect 2
Knob 3 scrolls left effect 2

Button 4 opens transition effects
Knob 4 scrolls transition effects

Starting on the right side
Button 1 not mapped
Knob 1 gain control right side

Button 2 opens right effect 1
Knob 2 scrolls right effect 1

Button 3 opens right effect 2
Knob 3 scrolls right effect 2

Button 4 not mapped
Knob 4 not mapped

I use the knobs below the top section for song scrolling and loading, loop loading and scrolling, loops latch and release, ins & out, cue points and a few other things.

I haven't even touched the shift key yet as I was playing with the VSL stuff. I am thinking about moving the VSL options to the 2nd page and making the front page more audio intensive...but I use so much video that I am not sure yet.

this x1 thingy is tempting.

Im useing my x1 and the denon and together they work great. best of both worlds for sure.

guitar center in chicago (on halsted) just got like 5 in (before any other stores in the midwest it seems) and i scooped one up right quick.

configuring it now, im working on a MIDIPipe file that splits one of the fx knobs on each side into two separate CC messages, which should allow me to map one knob to two separate fx within SSL 2.0 to create a DJM-800 style single-knob filter sweep.

Interesting! Share your config files after?

^^^yes please

Making progress except...

Whenever I unplug, and re-plug the X1 in, it doesnt save my setting for the off-state backlight.

So i put it at about 50%, unplug the X1, plug it back in, get the light show, and then no lights come back on except the green hotcue/midi light.

i tried saving the template and everything, i have to go back into the controller editor software and move the slider in prefs back up to get the LEDs to come on EVERY time i plug the X1 in.... annoying!

anyone else having this problem? Ive installed the lastest Controller Editor software and the latest drivers (same version thats on the CD)

oh and it doesnt seem to matter if the "start in MIDI mode" box is checked either, it always starts with the HOTCUE button lit green, even though the checkbox defaults to UNCHECKED...?!

Konix? Any ideas?

watchin..... waiting.....

Save the controller file, reboot, then when you start up again open the controller file (then you can close it again) and it should work.

wow that fixed it! not sure why/how, but it did.

now im having another (possibly more serious problem). ive been playing with my MIDIPipe setup and got some really awesome MIDI wrangling set up to allow 1 fx knob/button on the x1 to control 2 seperate fx banks in SSL (combined with Konix's suggestion in his youtube video to make the momentary/gate buttons light when pressed), but suddenly MIDI output from the X1 has gone completely haywire.

MIDIPipe no longer sees the output from the X1 so none of those mappings are working, but its still sees the X1's input... also using MIDI Monitor, the X1 sometimes doesnt even show as being connected (no MIDI output sources) even though it shows up fine in the NI Controller Configuration software...

and lastly, sometimes MIDI monitor will show the X1's output (as "MIDI input port 0") and will show activity when turning knobs/pressing buttons, but Serato recognizes NOTHING from the X1 when in MIDI learn mode...

didi get a lemon? should i start a new thread? halp!

to clarify, the X1 is selectable in the "Midi Out" module of MIDIPipe, but it is not selectable in the "Midi In" module...?!

YES! got it figured out.

Using the "hijack" function in MIDIPipe completely borks the X1. I had to delete the X1 profile from Audio MIDI Setup utility to get the MIDI output from the X1 back.

I've also mostly finalized my MIDIPipe file along with my Serato xml file to allow some wicked filter sweeping!

Prob wont have time to post it today but hopefully tomorrow when i can get all the necessary config files together (MIDIPipe file, Controller Editor file, and SLL MIDI.xml file)

so excited to use this thing out this weekend :)

no wonder my denon seems so much simpler, i like the x1 but denon was plug ans play witch was nice, i know not enough buttons, ive heard it all. i like both dont get me wrong.

Kontrol X1 is pretty much plug & play too, just drop the settings in the Serato MIDI folder and you're done. But people like to customize it. That's why they keep talking about Midi Pipe, settings, and stuff like that.

For anybody in il who wants a x1, the gc in highland park and been closed for 2 days for power issues so they havent been able to sell there's out, my boy who works there said they should be open tomorrow hoepfully. they still have two full trucks to put out.

This might be a bit of a stupid question, but can you use the Maschine with SSL?

I would think you could??? It's a MIDI controller.

Yup

Yeah you can use the deaf


exactly. you can definitely use the default Scratch LIVE profile that the X1 ships with, or theres even a 2.0 mapping on the NI forums that you can download, but i like to super customize my mappings, hence all the extra trouble. But its worth it :)

I have seen the Konix vids on these - anyone else got video rocking on an X1.

ya but u just plug the denon in and thats it, for mobile djing its alot more productive and for me it sits in a better place then the x1, the x1 takes up way to much space for mobile or clubs i think but i like my x1 to.

So it's just for bedroom DJ's then? Wow.

def dont think it takes up too much space at a club, quite the opposite actually.

when i was using the LPD8 i was always having a hard time finding a good place to put it.

in front of the mixer it was too low/got in the way of my hands on the x-faders/up-faders and headphone cable depending on the mixer.

on the laptop stand in front of the laptop sort of defeated the purpose of not having to reach for my laptop to control SSL.

i usually found myself placing it vertically either next to my laptop (if the booth allowed for it) or between the mixer and TT on top of something, much like the X1 sits on its bag/stand.

i love the placement of the X1, it feels much more like a natural extension of the mixer to me.

just bought one likin it so far. is there a way to switch from scrolling through songs back to scrolling through crates?

you can map a button to switch tab focus in the MIDI assign panel that shows up when in MIDI assign mode.

kinda wish i could use the left rotary for crate scrolling and the right one for tracklist scrolling tho!

can some of you guys post pics of where you have the x1 situated with your gear? Personally i'm interested in coffin pics, but i'm sure others would love to see any kind of x1 pics.

BS. Have you looked under the X1? See that little dimpled hole? That's so it sits on a turntable platter perfectly, and the physical size is exactly the size of the platter. Jeeze.

I don't see how it takes up too much space either, It fits perfectly in between the TT and mixer. Will post up some pics later.

konix.
how would 2 - X1's favor in this coffin, situation.
you got the DDM so you should kinda know the dimensions of the rack mounts & the X1.
picasaweb.google.com

this is basically the main reason i wanted to buy one...i thought that's how it worked anyway. can it be mapped to do this?

Here's how I have it in my setup....

www.iplaythemusic.com
www.iplaythemusic.com
www.iplaythemusic.com

Each rotary knob has 2 functions, one is the obvious, moving left and right or just like a regular knob would work. The other function is as a button...just push it down.

Why not use the push down function to move windows and the knob to scroll through whatever window you are on?

Mine is not set-up so I cannot try this out today...

I was at the WMC this weekend. I asked Shaun how to do this. By pressing TAB on your keyboard will do this.

that defeats the purpose of the controller then? Pretty sure you can map tab focus in the 'Show MIDI Panel' section after you click the main MIDI button.

I have to mess with it... Let me know if you can...

Of course you can midi map the "tab" button.

Denon fits much better for my set up, not everybodys. Some of you need to chill the f out. Its just a piece of equipment.

Dude, it's ok to say that something works well for you but to then say the X1 is good for nothing but bedroom DJ's is just a little bit over the top.

Different people have different styles and use different equipment. You need to realize that.

i never said bedroom dj's, we all started as bedroom dj's for sure, i just meant its been easier for me to use denon out then the x1, again i love the x1 but for me the choice is the denon thats all. i get ur point but god forbid you voice a opion on here all hell breaks loose and even worse if konix loves it forget it. people freak. it cracks me up. i have both and love both.

^^Haha you just gotta accept, some folks got more juice than ya...

my first time ever DJing was at a 4000 capacity megaclub in Ibiza, i thought that was how it was for everyone?

:)

Watchwww.youtube.com

I prefer pushing the button to load songs to corresponding decks, I think midi-mapping the tab would be the most convenient

i have tab switch and add to prepare list mapped to the FX1 and FX2 buttons under the right side browse encoder. works pretty well.

I agree 100%. Mine is set-up this way as well.

Okay I did it!

www.serato.com

or better yet

www.djtechtools.com

post a video..

no time right now! i might try to soon though.

Lets not make this into NI vs Denon war. I've used both, and like dj freestyle I prefer the Denon. (I've got the hc1000, friend of mine got the x1) That being said, if you get either one you'll be more than satisfied. I don't agree that any of them blows the other one...

The X1: great set up software, espcially the dim lit function is nice, 32 buttons (including push rotaries), 12 rotaries (4 of them "endless") 2 pages of midi. Lighter than the denon, a little bulkier, vertical layout. bag/stand available. A tad more pricey than denon.

The hc1000: A little easier to use out of the box, nice blinking function when loops are active. No dim light function (At least not yet, Denon, this would make a nice extra, as I understand it is possible to light them up 50% ?) 45 buttons (including push rotaries), 4 midi pages and shift functions on each page, 3 endless rotaries (with extra shift function). Ssmaller form factor, a little heavier. Horisontal layout. A little cheaper. No bag/stand yet, but built in mount threads under it and should eventually available (I believe Denon is working with UDG...)

With a little creativity you should be able to make either work perfectly for you, both function wise and placement wise in the booth. So what it boils down to; try out both and get the one you like the most...

After all, thats what djing is all about - creativity...

One other thing about the X1 that is very appealing (at least to me) is that you can tell when you are on midi page 2 (shift key lights up) and you have no idea what midi page you are on with the Denon.

Sure Justin I get that one, It would be nice if Denon included indicators for each page.

Still, most of the time, I use the native page. You can almost always see if you're on that page (page 1): tap button lights up if no track is loaded (or bpm is missing), cues and loops light up when tracks are loaded (I alway set at least one cue for tracks at the beginning, ie first down beat... - using play from first cue point)
And whenever changing pages the hc1000 lights up showing what page you've engaged.

Been using the hc1000 for almost 5 months now, and havent had any misfires due to midi page confusion, yet... took me about a 1 week getting used to switching between pages.

So basically I've set it up like this: Page 1 native, Page 2 mapped similar to native, only switched tap button for play/pause (ie "all internal mode"...) Page 3 mapped for FX. Will probably map page 4 for VSL (Not yet gotten into video)

Also a function that I like a lot, is the fast track search, not sure if that can be done with any other controller than the hc1000 ?

But again, get the midi controller you like the most, both of them are nice.

Can someone please help me with the Bonmes software... :-(

yeah sorry ive never delved into it very deep so im not sure how to use Bome's!

I would looove to use my lights on my X1....... But cant find out how to use bomes and the X1.

Here is how I have the X1 and everything else:

i815.photobucket.com

i815.photobucket.com

Very nice look...very clean.

Thx!

Ok... I am having a problem with my Kontrol X1. I just did a clean install of windows 7. Since then my Kontrol X1 is not being recognized automatically. I used to just plug it in and it would turn on and the lights would come on. Now it's plugged in and the only way I can get it to work is if I open the N.I. Controller Editor software. once I run that I get the light show and It is on. I never had to do that before I did the clean install.

What am I doing wrong? What did I forget to setup?

That's interesting because on my Mac I need to open (then I can close it) the controller software before it will work.

yup... thats what I have to do now but didn't before. I wonder if I had it setup different before.

In the Control Editor preferences (or in Traktor), do you have the option "Start in MIDI mode" checked?

AH HA... I will check for that when I get home...

i got another question regarding the kontrol x1. on the cjd´s 800/1000 you set the cue. not HOT CUES, just the normal orange lighted button next to the play button. when you push and hold it it will play the song from the moment you cued it until you release the button. then it stops! pushing the button will do it over and over again. i believe most of us are familiar with that function. anyways the question is:

is that possible with serato / kontrol x1? you know like without having to play the record...

thx

I know what your talking about. Would be nice if you could. I'm sure their most be a setting to do that.

Yes, just press and hold the cue button (or in this case, the button on the X1 you have mapped). This is how the cue behavior already works when the control vinyl is stopped, or if in Internal mode, if the play button isn't engaged.

Whoops, spoke too soon, looks like it only works that way in Internal mode only, not Relative.

yeah... i know! and that sux! i love the way you can kick in drums or beats that way...

Would only work in internal otherwise you have to have the control cd or record playing to control the music, it make sense why it would not work in relative mode.

That's a feature that's already included on the SP6 sampler. I wish they would incorporate that into the main decks.

likewise!

I think it also functions this way in HID mode if you're lucky enough to have access to one of the few decks that allow this.

bought one of these on the weekend after watching Konix's videos and then seeing a few in a local shop. Really like what it's allowing me to do in my sets already.
Still haven't figured out the exact sequence of events to get the lights to flash when I touch them. I'm using midipipe and the controller editor. They light up sometimes, then sometimes I notice it's just the ones I've set to toggle.
anyway, cool piece of gear...

I will let Konix chime in... I have mine set up really nice. You need to have Midipipe running in the backround for it to work.

it's weird. I've had it working fine on several occasions but sometimes the cue buttons aren't lighting up when I push them. No big deal, just gotta find out what I'm doing different to the times when it does work.

...and yes I have midipipe etc running.
How do I make the rotary encoders scroll my library on the shift page aswell as the first page? i.e. duplicate the midi commands.

You have to assign the knobs the same CC# in the Control Editor app, on both pages.

thank you much...

and thanks to you also my friend....

MIDIPipe LED feedback wont work if Controller Editor is open at the same time as MIDIPipe.

This was a problem I noticed too until i realized it was only not working while Controller Editor was open.

Do you have Controller Editor open?

yep, that'll be it. Nice work.
I'll confirm and get back.

So I see N.I. changed the crappy design of the case. My zipper always gets stuck and it's almost imposable to get it in and out of the case. If I take the cover of it's so hard to get it back on. I am very unhappy with this thing. I am gonna call today to see if they will exchange it for a new one.

Take a look : www.native-instruments.com

I never saw the old design. Is the new design so that it stays inside the bag like the picture shows?

Thats what it looks like. It also looks like the got rid of the zipper an replaced it with a sleeve. At least thats what I hope they did. I hope they made the case a little bigger too. It just fits inside.

I'm gonna call them at noon eastern time and see what they say... cuz I really hate taking it in and out of the case every weekend. It really is a bad design. But love the controller ;-)

new case? ah fuck! i dont mind the one now, its a bit tough getting it out once you've put it in (that's what she said)

Dose you zipper work ok? No problems with it?

Yeah, its been fine for me

I would hope they will replace mine since its only about 2 months old. I will post what they said. I'm calling an ten min's. They better make things right...

Wow... They are shipping out the new one once they get them in. No questions asked... I guess they are aware of the flaw... They said they are getting them in in 2-3 weeks.

Wow...maybe I should give them a ring

yup, that case design was pretty shit. Really hard to take the X1 out but kinda neccesary to have the stand for operating at turntable height.

thanks for the heads up on the bags. a mod at the NI forums got pretty defensive when i asked if they would replace older bags but it looks like they might be willing to anyways.

I have the older bag. I don't have any problems sliding the unit into the case, I just tuck one end in, then slide the other end down. It's a snug fit, but I just take the unit out with one finger at either end of the unit and do the opposite of what I described above.

The zippered lid panel is kind of cluttery on the old unit, but I don't suppose the new version solves that either. I sometimes just take the unit out to gigs in the bag without the zippered lid.

pretty sure the lid on the new one goes down into the case to create the top of the stand, which is why it has those leather looking strips across the top.

I could see them getting upset if nothing was wrong with it. But I guess the one I got was messed up really bad. It needs to be replaced. I'm not just trying to get the new bag. I just want one that works.

With the new fx in SL 2, it'd be nice to see a dedicated controller similar to the Kontrol

well the fabric feels like its going to tear every time i put it in/take it out so id say thats a little ridiculous considering it was $40, but yeah well see what they say. going to call tomorrow.

serato would definitely do well to have rane or a partner build a similar controller specifically for SSL!

My X1 dropped this morning. Though those bandits at FedEx have clearly battered the box about.

I've been watching Konix's video all week (Thanks Konix) and I'm going to try and get to grips with it later.

Would you guys recommend the case? Even for raising it?

I've got that UDG Creator bag though after years of taking it to clubs and overseas it's kinda weathered and nearly all but one of the zips has broken off - expect a bit more considering how much I tilled up for it! I don't think it will provide ideal protection now I've just typed that.

the bag is worth it to protect the X1 and the fact that it doubles as a stand is a huge bonus. playing with that thing at sunk below your mixer/tables is way awkward.

+1

Cheers you two. I'll source one over the weekend.

LED on and off light inconsistently working and only random buttons will lit up with midi pipe running? Any suggestions to make it work? Thanks.

Got it figured out.

Weird. Just got to my gig and fired everything up after messing around all day and now nothing works. :-/ I'm not even getting the buttons to light up when pressed.

I used the USB cable that used to power my SL1 unit - I left the cable I got that I'd been using today with the X1 at home.

Crazy as it sounds, though the cable is kinda loose and when I moved it the lights flickered. Obviously I got edgy and thought whether I was about to fry it something crazy. Being brand new and all that. Could the cable have anything to do with it connection wise?

Just clutching at straws here as I've pretty much done everything I did earlier today.

Weird. Annoyed too.

Is the X1 cable plugged into a powered usb port or the laptop? You may not have enough power going to it.

got the x1 - as konix said, dope controller it is! mapped efx, loop roll, cue, vsl - sampler, dunno where to put it..

now i gotta find me a serato/rane sticker to cover traktor logo

anyone received their overlays yet? Mine didn't come with a serato one...I did the whole thing on the NI site, haven't received anything.

this was asked and answered earlier in the thread...

I got my serato overlay from the x1 I bought. My x1 worked perfectly without running the midi pipe in the background. Turned on my MAC and the x1 controler remember the last session with serato.

The buttons won't light up when you push them if you don't use midipipe.
So yes, the X1 will work, but not as effectively as it can.

Hey everyone

Yep MidiPipe running in the background. I tried Konix's configuration along with OCD's and the beta one SSL 2.0 one from NI.

During this time when in operation the Control Editor was closed down.

The X1 is powered by USB directly to the latop. Had no problems during Saturday day time when making sure everything was sound before hitting the road for the gig.

I'm going to try going through it all again tonight. I know it's going to be something stupid.

Thanks for the help / assistance so far.

I used the X1 at my last gig and it worked flawlessly. Trick is you have to sometimes open the controller software briefly and THEN open midipipe (as stated...the controller editor cannot be left open and must be closed before starting midipipe). It's also been hit or miss with it remembering the last midi config (usually it does though) so I always save the config before I close (if I've made any significant changes) and then reload everytime I start the program. It's gotten to be so this is the ONLY midi controller I use now. My only complaints: needs bigger buttons and a fader

Now i know why i love my denon so much more then my x1.:)

You keep saying the same thing and people keep telling you that using the X1 with the midipipe is an ADVANCED use of the X1. And you keep being told that using the pre-set X1 set-up and not wanted every light to give to LED feedback works 100% flawlessly and has far more options than the Denon.

SO...you have been told again these same things. Now please go an play with your Denon in private somewhere since you seem to be having some sort of relationship with it.

Ha ha... nice...

Weird but I don't have to open the midipipe to work the X1. All the buttons turned on and off the way I config it e.g efx, samplers, etc... So far so gooood. No issues.

peeps, you dont need midipipe to use the x1, just for MOMENTARY LED feedback on the blue buttons and other advanced functions.

Yep. Midipipe us just to get the buttons to light up when pressed. Just for asthetics...

i think


i think AFTER you setup the light ON/OFF state of the button, no need to open the midipipe after that.

always restart your lappy every now and then to test the setup if it's working properly.

Aw justin if that makes you feel better then go with it little buddy.

midipipe has to be open in order to do its thing.

just try NOT to open midipipe (of course AFTER everything is setup). i just did. and it works. let us know.

the blue momentary LEDs also light up?

i dont have my x1 right so cant check for myself :)

right *now

someone with a pc, using a midi translator for x1 ?
i've got my x1 now and wan't them buttons to light up.
checked the konix tutorial, but unfortunately he's using a mac ;) and midipipe, which is not available for pc.

You can use Bomes but I have no idea how to use it. When I was using a PC I tried to use it... Sorry I can't help you out with that program. It's a bitch...

I like the fact that I don't have to touch my Mac. But I'm not sure how to make this a part of my setup. I'm using a MacBookPro, but ALL of my music is on external drives. My Mac only has 2 USB Ports. I'm using one for the SL3 Box and the other for my drives. How can I get around this, so I can add the X1 to my setup? Thanks for your input..

Usb hub....

or get a fire wire external

+1

Or upgrade your internal drive..

+1 Thats what I had to do. SL1 + Kontrol X1 on my two usb's then my 1tb on the 800firewire.

I put a WD Scorpio Blue 640GB hard drive in my MacBook Pro, so that should hold me for awhile. I just have my SL3 and my X1 on my usb ports. Upgrading your internal is the way to go...........

Wait, toshiba is going to made some internal HDD 2.5" that turn at 10 000 rpm (like velocyraptor but for laptop) :D
Or buy two velocyraptor in raid 0 with firewire interface that 'll rock :D (but not very light and ergonomic XD)

Anyone know where to get the new style bag/case in the USA? Every place I looked is either out of stock or it's the old style bag (at least by the pics).

Are you talking about the bag for the Kontrol X1, Konix? Is new style the one with the zipper and old school the one with the velcro? Have youo tried the shop on the NI website? I bought my bag (with the velcro) directly from NI, but here in Germany. I have to say, when the Kontrol is sitting on the bag, the Kontroll is a bit too low, because the usb connection is a bit bend up.

I just gave up on trying to get the bag myself and just made a sort of battle bridge for my X1. I got the idea from seeing the Road Ready battle bridge made for mixers and when I'm on the go my X1 and bridge fit inside my UDG Creator bag. It blends right in, it's light and I never touch my MacBook.
img686.imageshack.us
img63.imageshack.us
img189.imageshack.us
img710.imageshack.us

Very nice...also I love the Simon turntable mats :)

What & how did you make that? Very nice bro...

would interfere with scratching and juggling on the R side. looks very clean though.

I made it outta sheet metal, I'm a mechanic by trade and I can fabricate just about anything. It looks like it would be in the way, but it's really not. Just imagine yourself with a 12" or 19" mixer, it's just as normal as having a wider mixer. I really favored the Denon at first because it was so compact and it fit right above my mixer and I needed no special bags or boxes to hold it in place. Now that I made the bridge it's like my X1 is just part of my control panel/mixer and I just have total control over my music. Not wearing down my MacBook is a plus and I can't see myself not having a MIDI controller ever.

You should make and sell:.

Velcro = NEW
Zipper = OLD

I would buy it....

I am really starting to love my X1.. only thing I wish it had was a fader with clean preset to do the VSL fade back and forth but I guess this is good motivation to just grab a new mixer with at least that built in.

is there a way to map one of the big knobs to scroll the crates, while the other one scrolls the tracks?

saw on the NI forum that its possible for traktor using some "TREE" value... but i tried on serato and it doesnt seem to have the same name or function or w/e.

is there a list a of all the functions you can call on serato in midi?

why don't you just assign one button for tabbing ?
thats how i do it.
pretty easy.

yea, i've seen that. But i'd rather just have one knob do crates, 1 do tracks... even easier than tabbing

Why don't you want to use the same knob to do all that, it's the easiest way!
Look I turn the knob to scroll through my crates, if I want to jump into a crate I just push the button and I'm in, turn the knob again and scroll through my songs. If I want to jump back to my crates, I push another button, which I assigned for this function.

If you click on the midi button in the SL software you'll see what is assignable.
Then in the middle of the screen is another button, can't remember the name...if you click that, a window is folding up and you can see more functions you can assign. I recommend to watch all the MIDI mapping vids Konix did!
Watchwww.youtube.com

thx for the suggestion dude.. but again, i know about the tab focus thingy.

trying to figure out if I can do it the way i described above. I know there are more advanced options that I cant figure out yet... seen dude messing with the xml file and the provided software midipipe.

so for those dudes, is there a command for "TREE"?

Not that I have ever seen. I mapped my tab to a button below the knob.

you cant do this in serato

Hi
I'm waiting for the kontrol x1
Now I'm using serato trough midi mode with my cdj 400, and a Korg Nanopad with a notebook Windows Xp.
I want to know if is it possible use serato with together 400, Nanopad and kontrol X1? Or is there some problem because there are 3 midi controller??
And what is the solution actually for we have windows instead mac (no midipipe), for the led ???
Thanks

And Excuse for my english I'm italian!

bome midi translator should work for led in windows.

yeah, but it seems that nobody knows how to use the bome midi translator.

Is there some guide or tutorial for configuration of bome midi???
And my first question?? Some problem for working with cdj 400 via midi, korg nanopad and Kontrol X1???
Thanks

Alright, after numerous inquires and requests (seriously, I get like 5-10 messages a week about this on my Youtube), I present...

HOW TO GET YOUR X1'S LIGHTS TO LIGHT UP ON A PC

You will need to download and install these two little programs

1) MIDI Yoke... www.midiox.com (direct download www.midiox.com )

***If you are using Vista or Windows 7, you MUST disable UAC before installing MIDI Yoke or it will not work correctly.***

2) MusicLab MIDI Device Connection Center... www.musiclab.com (direct .exe download link... www.musiclab.com)


So download and install these two things, note you will need to reboot after installing MIDI Yoke.

Now some background info. I've stated that you will need to use Bome's MIDI translator on a PC in order to get the X1's LEDs to light up. However, I've never really tested this and just assumed it would work and thought it would be just as easy on Windows PCs as it is with Macs with MIDIPipe. Unfortunately as we all know by now, that's not the case. Windows doesn't work quite the same as OSX does (what a surprise). It's possible with Bome's to light the LEDs on the X1, it's simple really, all you do is select the MIDI Thru option and viola, the LEDs light up. Problem is though, load up Scratch Live and try to map it, it won't work, as Scratch Live cannot "see" the message the X1 is sending as Bome's is the "middle man" and blocking the messages. Cause when you enable MIDI Thru mode in Bome's, any messages the X1 sends just gets sent back to the X1 (i.e to light the LEDs) and not to Scratch Live. This is what you need MIDI Yoke for, to send the messages from the X1 to the virtual MIDI port, than to Scratch Live, but back out the the X1 as well to light the LEDs. Macs/OSX have this functionality already built in and why all you need is MIDIPipe, Windows does not this functionality, at least not by default and why you need MIDI Yoke.

Anyway, instead of using Bome's, we're going to be using the MusicLab MIDI Connection center. It's a lot simpler and easier. Just open the program and you should see this...

i48.photobucket.com

On the first row, select the X1 as the input, and MIDIYoke1 as the output, in the second row, select MIDIYoke1 as the input, and the X1 as the output...

i48.photobucket.com

then press the two Connect buttons in the middle to connect the ports...

i48.photobucket.com

and that's it! Now the lights on the X1 should light up (those that are set to triggers in the X1 Control Editor, remember toggles will already light up regardless). Now just go into Scratch Live and map away (if you haven't already).

Hope this help those with Windows/PCs that want their X1's LEDs to light up.

Video to come soon.













And of course, we wouldn't need to go through all this trouble if Scratch Live just had MIDI output. C'mon Serato and get on it! ;)

This discussion has been really helpful. Just by reading this discussion I've been able to customize my X1 and Serato mappings in tandem to make it do (almost) exactly what I want. So first, big thanks to the contributors thus far!

I'm getting stuck with one minor issue with the LEDs. Keep in mind that I'm not using third-party software (I'd like to avoid that for now, just because lighted-buttons aren't all that important to me).

I haven't figured out how to make the LEDs light only when a button is pressed, and then go dim when the button is released. I know that the X1 can handle something like this because the SHIFT button has that functionality already. ON when being pressed and held down, OFF when you let go. I specifically want this for censor buttons. Again, not a huge deal, but it seems like it'd be a simple setting.

Back in 2009 I was doing a lot of crazy glitching stuff without any controllers at all : Watchwww.youtube.com ... I had a NanoPad for a while, and NI just sent me an X1 as part of a sponsorship... I think this might be my new favorite box.

M

That was a interesting video. Post a new one please

Unfortunately this isnt possible yet without using a 3rd party app like MIDI Pipe. If SSL had options to send MIDI messages back to the controller, or NI's controller editor had an option to light up buttons that are set to momentary (press/release), it would be a different story. Hopefully one of thee things will get implemented in the near future though.

Thanks OCD, I figured this after checking out Konix's tutorials. MIDI Pipe is plenty simple though, I'll just use the workaround in the meantime.

anyone got a demo for video sl on this one? im thinkin of buying x1 or the dicer...pretty confused here now..

i have a lil video demo in here, and settings, no vsl demo but, you'll get the idea
www.scratchlive.net

ok ill check it..because i use a usb midi interface for the crossfading of my vidz..if i buy x1 do i stil need another usb interface for the fader transitions...

no you can use the x1 to fade videos. i dont think you could fade video with the dicer tho.

there are no knobs on the dicer to fade with.

you dont really need a knob to fade video, you can map the auto and instant scrolls top button, ive found in most cases its more efficient like that anyway

well its very hard i need to use a midi interface to crossfades my vidz..and besides mbp only got 2 usb ports..:(

whats very hard?? Also use a USB hub, right now i use a korg nanokontrol to crossfae video and effects, a denon hc 1000 for loops and cues an external HD all running off a hub

Thats makes sense.

so is it ok to use a powered USB hub for midi Controllers? coz i havnt tried it..im afraid ill be having a problems with my sL for dropouts..so now it make sense...thanks bro

hubs are perfect for midi controllers just dont plug your SL? into the hub, the SL box gets its own USB port and the rest of the midi controllers go on the hub. i even ran it on an unpowered cheap hub and still havd no issues 0 dropouts

ok thank you so much bro....

After doing research on the TK X1 I'm going with that over the dicer(s). DO WANT!

I ended up using MIDI Pipe, which was incredibly easy after following Konix's tutorials. Thanks!

Konix:

Thanks for the great vids! Did you ever upload your mappings? I searched a lot of the forums and can not seem to locate them, though I have seen references to them. That is for the X1 by the way.

im thinking of getting the x1 too.it was a choice between the dicer and denon.
im using serato 2.0.is there anything that cant be mapped and these dreaded lights have they been sorted out? cheers

i there,
i'm doing my own mapping for the Kontrol X1 and I have a small problem, hope someone might help me.

I'm on MAc using midipipe and scratch live.

Basically i want the FX buttons next to the top 4 knobs to stay lit up when the effect is active (and lit off when the effect is deactivated).
I mapped it in to the controller editor as "toggle" (not "gate") as I want it activate until I press it again.
What happen instead is that I have to double click the button in order to deactivate the lights and the effect. Basically at the first click the light goes off (but the effect stays on) at the second click the effect switches off.

If I map the same button to "loop roll" for example, it behaves correctly.

It's really frustrating, does anyone know why that happen ?

thanks

When you map it in ScratchLive, cycle through the control settings ('c' on your keyboard) I believe...you'll go through a bunch of options like 'absolute', 'relative signed bit', etc. See what works for you.

You need to go into the Control Editor and change those buttons' on/off values to 64 and 66 instead of the default 0 and 127, then you won't have to hit the buttons twice to turn on/off. Also assign them as absolute controls in Scratch Live, not any of the relative options.

Konix you are a genius :-)

i'll have a proper play later, but I'm sure it will work.

Do you have your supercool mappings anywhere (for us to download) ?
Thanks for the videos btw.

thanks!

I think changing it to absolute in SSL will resolve it. I have the default values of 0 and 127 but I am using OhCeeDee's midi pipe template.

I swear Konix sleeps with his X1

he does!
Konix the magic numbers solved the issue.
Just out of curiosity, where the numbers are coming from?

PS:
@dj spinart : buttons were already on absolute , I previously tried to switch to relative and so on, but nothing, the 2 numbers suggested, solved it.
magic :-)
thanks !

That's weird unless OhCeeDee's midi pipe changes something on my end. This stuff is all new to me.

Anyway I'm glad you got it working. Konix is the man and has helped me out a bit.

Guys Please help...

Just got an X1 and I have mapped a few buttons in SSL. The problem is I have to press the X1 buttons twice for it to react in SSL...

Anything thing I need to change???

Change the mode from gate to toggle in the software that comes with the Kontrol X1.

I have done that. I still have to press twice in SSL.

Hmm, when I change between toggle, gate, trigger, increase,...than the buttons acting different like they supposed to do...did you save the settings? Ot leave the software open in the background, change everything, try everything out and when you are satisfied than save it.
I highly recommend Konix video tutorials about mapping the X1. You'll find 'em here on the forums or on Youtube (he goes by the name Seratotutor).

this is a on going issue..
not just with the X1

www.scratchlive.net
www.scratchlive.net
www.scratchlive.net

Just follow konix advice and your x1 double tap problem
will be solve.

worked thanks.



hi,

i have a problem with the browse knob on x1. i can only use one knob for scrolling. for example if i assign the left knob, the right knob doesn't respond when i turn it and vice versa. i'ts not a huge thing but it's annoying. i might be wrong but i think that this problem occurred when i installed the software provided in konix' link:
serato.com (don't get me wrong, i am really thankful for this konix!)

help.. anyone?

Did you assign both scroll knobs the same CC# in the Control Editor? Got to do that.

solved! thank you very much konix.

Is this possible.... ???

I want to have 2 buttons for each deck assigned to Absolute and Relative modes. I'd like it so when I hit ABS button, the light for button assigned to REL mode automatically turns off, and the ABS button light turns on.

So basically 2 buttons that kinda talk to each other, so only one button is lit up at any time.

Right now I just have it as a toggle, so when I want to change modes, I just both lights on or off.

I'd like this too Jig T if anyone can help with this?

...one thing i also noticed that i'd like to alter if possible

It appears the SUPER KNOB is on the same MIDI Number as Auto Loop Select...

I've set my X1 up virtually the same as the original text that is printed on the device itself with Buttons 1 & 2 and Knobs 1 & 2 (labelled FX1 & FX2, and Dry/Wet) set up for SUPER KNOB, but when i then configure the Size/Loop infinite Knob (with push to select the Loop Length) it overwrites my SUPER KNOB config from Knobs 1 & 2!

Any ideas? Can i change the MIDI assignment number in Serato?

I'd like this too Jig T if anyone can help with this?

You'll have to go into the controller editor and change the assingment numbers if I'm understanding you correctly.

white X1s

sphotos.ak.fbcdn.net

Nice Dub, with them you won't bee needing your white vinyl, just send them over to me, I'll be happy to take them off your hands ;-)

Very nice looking.

those White X1s are Pete Tongs, not mine. He may be able to flow a pair of whites for you but they will probably be for Traktor.

haha ;)

I use the Denon and one of these for my EFX: www.kentonuk.com

The Knobs are solid and have a perfect size

www.kentonuk.com

Hello can somebody help me out with mapping the 2nd page with the traktor X1 Controller? Do i need to have the Traktor Controller Editor open to assign the 2nd (shift) page? Somehow when i assign midi to the 2nd page of the controller (4 xample rotary knob for a Loop Roll) it has an effect on dze 1st page Basic) of the controller as well. How do i separate the to pages from another? Do i need to change midi channels?

Here is what i want to do: I loaded down a preset from the Traktor website that works with version 2.0. I found a link here in the forum. It has the auto loop assigned to the basic page for the rotary knob. For the second page i want the same knob to be assigned to Loop roll. Each time i make changes to the second page it also assigns it to the first page. Understood?

Can anybody help me? Or come up with some nice settings, that i can download?

Correct me, if I'm wrong...I did my mapping a while ago, just following the steps of Konix mapping vids...
to map the second layer, the traktor kontroll editer has to be open and if you are on the second layer, you'll see that all the buttons and knobs have different numbers, than the same buttons and knobs on the first layer...assign them, like you did before and it should work.

Gents,

I have set my second page to mix in internal mode and have set 2 large push-button knobs to control the pitch. I have set them to:

Type: Control Change
Mode: Absolute
Range: 0 to 127
Step: 1

Now the problem is that the variation is 0.25 change on the pitch everytime I change it. Is there any way to reduce the step value below 1 or maybe another arrangement to get the pitch change to be less than 0.25%?

asign other knob to fine pitch ;)

^^ what do you mean mega-b?

I actually found a way - I changed the pitch range in serato to 8% (from 16%). now my pitch increments are much smaller :) (+- 0.12%)

anyone using this for video and how do you have it set up/mapped?

For VSL - I only have the 4 large knobs set for changing effects and transitions...

BREAKING NEWS!!!!!!!!!!!!!!!!

I HAVE GOT THE BUTTONS LIGHTING UP, NO SOFTWARE NEEDED!!

i have found a way of getting the buttons to work normally in "toggle mode"

adjust the value's from the standard 0-127 to 64-68 once you've done that the button will light up and stay on untill turned off like its supposed to.


i hope that makes sense. enjoy ... dave

A big thank you to Dave D! I remeber Konix said something like that about changing the value, but I never tried it out...it's really time to do it now!

cheers dude ;)

Is there anyway to get a button to light when pressed but off when you let go? I use the REL & ABS buttons to enable both these functions in Serato and just want a confirmation (for want of a better word) that i have pressed the button.... and i like the blue light :0)

Do they stay lit when not activated (for dark club situations)?

You can set the level of how the lights stay, when they are not activated in the software that comes with the X1. Konix shows how to do that in one of his vids.

But his video shows with midipipe. I want to know if it will work with this new method.

yeah go into file >prefrances>controller and you can adjust the on and off state brightness of teh buttons.


with regards to midipipe, you dont need it anymore simples

Yep, exactly to set the level of the brightness you don't need MidiPipe or anything else.

Sweet

I thought midipipe allowed feedback with buttons such as cue, not ones that toggle like FX On or Off.

Without midipipe, the cue buttons wont light up when you depress it.

i apologize if i missed this, but is there a way to you can don't have all for four fx buttons lit up at the same time...IE fx1 on the left side turns off when fx1 on the right side is pushed???

Hey thanks for that. That tottally helped. but hey, just a question for you. do you know of any site that will explane how to get "Bomes Midi Translator" to tell the X1 how to use the lights on the buttons for trigger modes such as the loop roll. I know the DN-HC1000S i own also has their buttons light up when a cue point is set as well. im wondering
if their is a site or a couple youtube vids that may gimmie the just of it so i may figure it out. Thanks,

Ha Ha... Good luck with that one bro. No one knows how to work Bomes. When I was using a PC I gave up and used it without the lights. Midi Pipe for Mac just works.

I was about to buy a x1 and now rumors are floating of a midi controller from rane at namm.

Really??? I will be soooo pissed. I have a X1 and just bought the Dicers...

What is wrong with the X1 or the Dicers, guys? Those are some good MIDI controllers!

The x1 is very cool and if rane does release one wont be much different im sure.

This is the way i use X1 and midi controllers: Watchwww.youtube.com

lol I love that green velvet track

Love cajmere aka green velvet and nice set up maga-b

thanks, there are: X1+Dicers+UC33, using the bridge

this is how it should be done...this style is identical to none.

Watchwww.youtube.com

nice skins!

So i did figue out how to use Bomes Midi Translator and its actually quiet Simple if anyone is interested. It actually take a total of about 30 seconds to get it working such as macs Midi pipe.

please do explain, i would love to do this nice and simple, but can't get my head into it.

Start a separate thread for it to make it easier for everyone.

BOMES MIDI TRANSLATOR AND X1 FOR SERATO

serato.com

The X1 is looking nice, but I think I am going to wait for the next great thing... :)
Any news on that Rane Midi controller rumor?

quick question... when i hit "SHIFT" on the x1 it does not stay on the second page. as soon as i let it go it jumps back to the first page. I will like to map the second page of the x1. Thanx to anyone that responds

never mind folks... i got it

Did you latch it?

changed it in the settings. thanx for the response justin

I have done all these steps and the LED's do light up when pressed, just the way i wanted, using windows 7 64bit. I have mapped the Kontrol X1 with serato the way i wanted and all works well. BUT!!!! After i connect the first line and second line in MusicLab (The LED's Do Light Up When Pressed) then open serato some of the functions that i have mapped dont work like they should, e.g. when using the browser knob it selects every second song or create not each one like it was b4. Also i have assigned the the Tab Focus to button FX1 on the Kontrol X1 and it does not work, and as soon as i disconnect the first and second line in MusicLab everything works as i have mapped it again. Can anyone help or suggest anything please? Cheers :)

Hello guys,

first of all thanks for everything. This tread was kinda useful :D almost got everything working. However i'm encountering one or two issues.

The most annoying thing is the shift button. it works but only if stay pressed. Of course i had a look in the controller editor but it appears that i can not change the settings of this button. As it actually is for the hotcue/midi one's. In the control editor i just have no value above this button at all. However still in the control editor if i press it, it changes the page to the shift mode properly.

Does anyone have an idea about this? I was wondering if there is somewhere a new version of the control editor which may allow me to change the settings of this button...

Cheers guys.

^I don't see anything wrong with it. The shift button does exactly what it is supposed to do, bring you from one page to the other, forth and back, so there is only 1 mode needed and it lights up, when you press it down (you are on the second page). The light goes off when you press it again (you are back to page one).

yea well maybe i didn't express myself well.
it would have been perfect if working as you described it.
But the point is that when i pressed it down the light doesn't stay lit up once released. So in order to access the second page i need to hold down the shift button otherwise i switch back to the first page.

I do know that i have to change the value of the shift button in the control editor. Here is my issue. I can't set this button as i dunnot have access to it in the control editor....
No value above the button, and no way to change it's setting. But i might do smthg wrong here....

Hope i've been clearer... thanks for your help anyway.

Did you work off of a clean template? I was running into issues trying to start from a clean template. I found it easier to start with the Serato Pre-Map Template and only change the buttons that I needed. This fixed the 'Browse' and 'Shift' issue for me.

i did use the serato pre map template...

hhmmm... I havent mapped my Kontrol X1 in a while. I will take a look at my mapping when in get home.

In the control editor software select the pages tab on the right - at the bottom you can set up the shift mode to either gate or toggle

u r awsome.... i never had a look on that... lame....
cheers.

Ha, you beat me to it.
In general you can select a mode for every button and starting from scratch is not bad. I did it. I watched Konix vids (look up Seratotutor on youtube), he made a couple of vids about how to MIDI mapp your X1, after that you'll be able to mapp it as you want to have it.

yea i did watch those vid for sure... i got everything working just fine. only this shift button was annoying. i guess i've been lazy not clicking on the page tab...
sorry...... and thank u for ur help...

guess who has two thumbs and just got an x1.

THIS GUY!

so now you just have to find a way to paint it white like all your other gear and toss that korg in the trash!

oh...already working on that.
matter o fact I was working on that BEFORE I bought the damn thing.
www.12inchskinz.com

funny though.
midi progression:

Nanopad> loved it, but limited to pads.
NanoKontrol> too busy, easy to get lost in its controls.
Dicer> much like the nanopad, but with 10x better placement on the 12z.
X1...we'll see what happens.

carl.... i found myself placing it in between mixer and Right TT when the majority of the music i was playing was DANCE oriented. When im playing majority HIp Hop i place it to the right of the right TT.

BTW.. buy the caring case it's like 40 bucks. Well worth it, protects your X1 and also raises it to your mixer and turntable height level

I have had one since the first week and never used the sample bank until last week. I put 6 samples and then placed them on the second page of the X1 (press the shift key). I love the fact that all I have to do is toggle the shift key and press on of the buttons and not have to open up the sample window.

I used the top half for the samples and the rotary knobs all mapped to the volume so I can control each one of them without moving my hand much.

Just in messing with this.

is theres a preffered load pattern to make it not so tempermental?
Heres what Ive seen thus far.

*You have to open the control editor everytime u plug it in to adjust the lighting.

*you have to quit and restart a new instance of midipipe everytime you plug it in
(Or else the keys wont light)

Ive saved my setting in every possible place.

The control editor has a preference under preferences (I think, not near my system) that allows it to run every time without starting up or having to be opened.

But midipipe does have to be open.

after about 4 months of use, i really like mine. it took about 2 hrs to get things right, but its a rock solid controller, really worth the 200$.

one question, that i know is somewhere in here:

if you assign the pitch to a knob, how do you get it to be the smallest percentage of +- change?

or, how can you make the channels that load the track work in both scenes?

becuase they dont show up in the controller editor on either page?
They are control surfaces 18 & 19.

and seeing how u cant change them in the editor.
or dual assign them in the ssl midi function...
you can scroll your library in scene two, but not use the depress function of the knob
to do it.

Assign the same number for both of them. Look at the controller numbers for the one you know works and just use the same numbers for the other ones.

On the knobs that both turn and push Look under the action tab on the right and select the push page.

This what you were looking for?

yeah, and no.

for any other action that would work.

but for 18 & 19 CC there is no representation in the editor.
I guess when its on scene 2 those buttons would different cc #s,
but u cant un-asign the load track from scene 1...which is essentiall what would
happen if u tried to assign the same action in SSL.


the other thing i can quite figure out.
toggle.
I understand how it works.
but I assign a toggle option to a button.
click it once> light comes on, effect engages. yay!
click it again, effect disengages, light stays on.
click it again, effect engages, light comes on.

basically taking 2 taps....which throughs the whole toggle thing off.
am i missing something? does it need to change from cc to start or something?
